Haas VF4 CNC Mill
Specifications:
Table Size: 52″ x 18″
Maximum Table Load: 3,500 lbs.
X-Axis Travel: 50″
Y-Axis Travel: 20″
Z-Axis Travel: 25″
Spindle Taper: CAT 40
Spindle Speed: 7500 RPM
Spindle Motor: 20 HP
Spindle Nose to Table Top: 4″ – 29″
Tool Magazine Capacity: 40 Position
Rapid Traverse Rates: 1,000 IPM
Cutting Feedrates: 650 IPM
Machine Dimensions: 122″x95″x100″
Machine Weight: 13,300 lbs
Equipped With:
Haas CNC Control
Wired Only 4th Axis Drive
Chip Auger
CAT
Ethernet Interface/Hard Drive
2-Speed Gearbox
Programmable Coolant Nozzle
Rigid Tapping
40+1 Side Mount ATC
Thru Spindle Coolant @ 300 PSI
