Mazak Variaxis i-600 (2-Pallet) 5-Axis CNC Vertical Machining Center
Specifications (subject to buyer verification):
Number of axes controlled simultaneously 5
Table size 15.75”
Table surface Height 38.39”
Max. workpiece size 23.62” Dia x 16.73” Height
X-axis travel (Saddle’s longitudinal movement) 20.08”
Y-axis travel (Column’s transverse movement) 35.83”
Z-axis travel (Spindle head’s vertical movement) 20.08”
A-axis travel (Table tilting)[Indexing in units of 0.0001Deg) –120° to +30° (axis control)
C-axis travel (Table rotation)[Indexing in units of 0.0001Deg) ±360°(axis control)
Distance between spindle nose and top of the table 1.77”” to 21.85”
(positioned horizontally)
Distance between spindle nose and center of the table 0.79” to 20.87”
(positioned vertically)
Max. load on the table (uniformly distributed load) 661 lbs
Spindle tapered bore 7/24 taper No. 40
Spindle speed min1 35 to 12000 RPM
Motor output 30 / 20 HP
Magazine capacity 40
Tool shank type HSK
Equipped With (subject to buyer verification):
Mazatrol Matrix 2
40 ATC
HSK
Chip Conveyor
Laser Tool Length Measurement
Probe – RMP60
Pallet Changer
Thru Spindle Coolant
