Capacity ………………….. 250 Tons
Overall bending length ……… 120″
Distance between housing ……. 100″
Bed height ………………… 36″
Top bed width ……………… 6″
Length of Ram Stroke ……….. 8″
Open Height ……………….. 16″
Closed Height ……………… 8″
Throat Depth ………………. 10″
Approximate speeds Approach …. 65 IPM
Bend …….. 19 IPM
Return …… 140 IPM
Cycles per minute Standard ….. 11
Hi-speed ….. 15
Approximate motor HP ……….. 20
Overall bending length ……… 120″
Distance between housing ……. 100″
Bed height ………………… 36″
Top bed width ……………… 6″
Length of Ram Stroke ……….. 8″
Open Height ……………….. 16″
Closed Height ……………… 8″
Throat Depth ………………. 10″
Approximate speeds Approach …. 65 IPM
Bend …….. 19 IPM
Return …… 140 IPM
Cycles per minute Standard ….. 11
Hi-speed ….. 15
Approximate motor HP ……….. 20
Overall dimensions: 144″ x 60″ x 98″ High
Approximate Weight: 22,000 lbs
Equipped With:-
– Accurpress Advantage Package (Proportional Valve Hydraulic System & Dual Ram Encoder Feedback System)
– ETS-3000 3-Axis CNC Back Gauge System (X, Y & R)
– ETS-100 Operators Console with Display and Palm Buttons
