Okuma V760EXM (Right) CNC VTL with Milling
Specifications (subject to buyer verification):
Capacity
Max turning diameter: 29.92″
Max swing diameter: 31.5″
Swing on carriage: 24.02″
Max work length (height): 30.31″
Max workpiece weight (w/ chuck): 1100 lbs
Height from floor to spindle nose: 42.72″
Travel
X-axis travel: 15.35″
Z-axis travel: 30.31″
C-axis travel: 360 (minimum control angle 0.001 Deg)
Spindle
Spindle speed: 20 – 2,000 RPM
Spindle nose shape: JIS A2-11
Turret
No. of tools: L/M: 12
Milling Tool
Milling tool spindle speed: 4,000 RPM
Motor
Spindle drive: 40/30 HP (30 min/cont)
Milling tool spindle motor: 10/5.7 HP (25 min / cont)
Equipped With (subject to buyer verification):
OSP-P300LA CNC Control
High Torque Geared Spindle
Milling Function
Touchsetter QTS (Manal/Auto)
Chip Conveyor, Rear Discharge, Hinge, High
Splash Gun, Coolant
Shower Coolant, Type B from Celing
Prep Only for Mist Collector, 6”
Spare M-Codes, 8 Sets
Air Blow, Chuck
Machine AOT IFG P2 M/W Lathe
Common Variables, 1000 Sets
Helical Cutting for X,C,Z
Negative Tool Radius Compensation
Rapid Traverse Override Switch
Kitagawa 24” Closed Center Chuck with AS-11 Adapter
