Haas ST35LY Multi-Axis CNC Turning Center
Specifications (subject to buyer verification):
Capacities Swing over Front Apron ……………………………………………… 20.5″ (520 mm)
Swing over Cross Slide……………………………………………………………… 20.5″ (520 mm)
Swing over Tailstock ………………………………………………………………… 20.5″ (520 mm)
Bar Capacity ……………………………………………………………………………….. 4″ (102 mm)
Max Cutting Diameter with ………………………………………. 12″ (304 mm)
Maximum Cutting Length (varies with workholding) …………………. 62.5” (1587 mm)
Travels & Feedrates X Axis Travels……………………………………………….. 9.4″ (239 mm)
Y Axis Travels…………………………………………………………………………… ±2.0” (±5 mm)
Z Axis Travels ……………………………………………………………………….. 62.5″ (1587 mm)
X Axis Max Thrust ……………………………………………………………… 4100 lb (18,238 N)
Y Axis Max Thrust ……………………………………………………………… 2300 lb (10,231 N)
Z Axis Max Thrust …………………………………………………………….. 5100 lb (22,686 N)
Standard Spindle Max Rating …………………………………………………… 40 HP (29.8 kW)
Max Speed ………………………………………………………………………………………. 3200 rpm
Spindle Bore ………………………………………………………………………. Ø4.62″ (117.3 mm)
Optional Spindle Max Rating ……………………………………………………. 40 HP (29.8 kW)
Max Speed ………………………………………………………………………………………. 2400 rpm
Live Tooling Max speed……………………………………………………………………… 6000 rpm
Equipped With (subject to buyer verification):
Haas CNC Control
2-Speed Gearbox
24-Station Half-Index Turret Option-BMT65-24Y
6000 RPM Live Tooling Speed Upgrade
Auto Door
Automatic Tool Presetter
Chip Conveyor Belt Type
LNS-SLUBZ31 – LNS Model SLUB-Z-3.1 Automatic Steady Rest, 1.38” to 6.5” Grip Capacity
12” Samchully MH-212 Hydraulic Chuck
