Awea CNC

Top AWEA models and specs to know

Specs vary by year, control, options, and exact configuration. Confirm all details on the machine listing before quoting a job around a used AWEA.

AWEA series or model	Machine type	Typical travels or capacity	Buyer note
LP-3021	Bridge type vertical machining center	AWEA LP-21 factory specs list LP-3021 travel at 3,000 mm X, 2,100 mm Y, and 760 mm Z, with 10,000 kg table load capacity. Premier's listed 2005 AWEA LP-3021 shows 118 inch X, 82 inch Y, 30 inch Z, Fanuc 18i-MB, CAT 50, 32 station ATC, 35 hp, and 22,000 lb table capacity.	Strong fit for large plate, mold, fixture, and heavy part work where table size and rigidity matter.
LP series	Bridge type machining centers	AWEA lists LP series X travel from 2,500 to 7,000 mm, Y travel from 1,600 to 3,300 mm, Z travel at 760 mm with longer Z options, and table loads from 8,000 to 20,000 kg.	Good family to check when the buyer needs a larger work envelope than a standard VMC.
SP series	Bridge type machining centers	AWEA lists SP series X travel from 2,100 to 4,000 mm, Y travel at 1,600 mm, Z travel at 760 mm, and table loads from 8,000 to 12,000 kg.	Usually a practical lane for bridge mill buyers who need capacity but not the largest LP or gantry machine.
AF-II series	C-frame vertical machining centers	AWEA lists AF-II X travel from 650 to 1,800 mm, Y travel from 510 to 800 mm, Z travel from 510 to 800 mm, and 12,000 rpm spindle speed.	Better fit for shops looking at conventional VMC work instead of very large bridge mill work.
BM-II series	Super rigidity vertical machining centers	AWEA lists BM-II X travel from 850 to 2,500 mm, Y travel from 650 to 1,000 mm, Z travel from 610 to 1,000 mm, and BT40 or BT50 spindle taper.	Worth checking for heavier vertical machining work, depending on exact spindle and control.
Mega 5 series	Bridge type 5 axis machining centers	AWEA lists Mega 5 X travel from 2,500 to 10,000 mm, Y travel from 2,620 to 4,700 mm, and table capacity from 8,000 to 20,000 kg or 2,500 kg per square meter. Premier's listed Yama Seiki/AWEA Mega 5 P3020 shows 118.1 inch X, 98.4 inch Y, 39.3 inch Z, Heidenhain 640, HSK-100A, 15,000 rpm, 40 ATC, and 26,450 lb table capacity.	Strong fit for large 5 axis bridge work where access, reach, control, and setup strategy matter.
FV and FCV series	5 axis vertical machining centers	AWEA lists compact 5 axis machines such as FV and FCV with smaller travels, rotary table configurations, BBT40 or HSK-A63 options, and 24 to 60 tool capacity depending on model.	Good to know if the buyer wants AWEA 5 axis capability but does not need a full bridge machine.



What AWEA is known for

AWEA Mechantronic was established in 1986 and is one of Taiwan's larger CNC machine builders. The brand's lineup includes vertical machining centers, bridge type machining centers, gantry machines, horizontal machines, 5 face bridge machines, and 5 axis machining centers. For used equipment buyers, AWEA often comes up when the job requires a bigger work envelope, a bridge mill layout, or a heavier machine than a standard vertical machining center. That does not mean every AWEA is the right buy. A used AWEA LP-3021, Mega 5, AF, BM, SP, or VP should be judged by the same practical questions Premier asks on any used CNC machine: what was it cutting, how was it maintained, what control is on it, what options are installed, and whether the machine fits the part size and tolerance requirements.

What to check before buying a used AWEA

For a used AWEA bridge mill or vertical machining center, pay close attention to:

1. Control type, such as Fanuc or Heidenhain, and whether your team is comfortable with it.
2. X, Y, and Z travel compared with your largest parts and fixtures.
3. Distance between columns on bridge and gantry style machines.
4. Spindle taper, horsepower, rpm, and whether the spindle fits your cutting work.
5. Tool changer size and maximum tool weight.
6. Table size and table load capacity.
7. Coolant through spindle, chip conveyor, probing, scales, and other installed options.
8. Power requirements, air requirements, machine weight, rigging needs, and floor space.
9. Service history, hours, alarm history, and whether the machine can be inspected under power.

Large AWEA machines can be very capable, but the logistics matter. A bridge mill with a 22,000 lb table capacity is not the same buying process as a small VMC. Rigging, shipping, electrical service, foundation, door clearance, and installation planning should be part of the conversation before the machine is purchased.

Options that can make an AWEA more useful

The right options can make a used AWEA much more useful. For bridge mills and 5 axis AWEA machines, buyers should ask about coolant through spindle, chip conveyor, probing, tool measurement, rotary or 5 axis capability, optical scales, spindle cooling, upgraded tool magazine capacity, and the exact head configuration. On a large bridge machine, the option package can affect setup time, finish, tool life, and whether the machine can handle the work you actually need to run. Premier can help review the listed options on an AWEA machine and compare them against the parts you plan to cut. If an option is missing, the question is not always whether it can be added. The better question is whether the machine still makes financial sense after the cost, downtime, and installation work are considered.

Useful AWEA support and manufacturer resources

AWEA's official website lists product families, factory specifications, and global contact information. For used AWEA questions, current Premier inventory, pricing, quote requests, financing, rigging, and shipping, contact Premier first.

1. AWEA official website
2. AWEA official contact page
3. AWEA production bridge milling specs
4. AWEA LP-21 series specifications
5. AWEA 5 axis milling models

Why buy a used AWEA through Premier Equipment

Premier has been in the used CNC business since 1988. The team understands that a used AWEA buyer is usually not shopping casually. These machines can involve serious floor space, heavy rigging, power planning, tooling questions, and application fit. Premier can help you compare a used AWEA against other available machines, review the listing details, check whether the machine fits your part size, and talk through financing, rigging, and shipping. If Premier has the machine in inventory, ask what can be verified, what is included, and what should be checked before it ships.

FAQs about used AWEA CNC machines

What types of AWEA CNC machines are most common on the used market?

AWEA is often seen in vertical machining centers, bridge mills, gantry style machines, 5 face bridge machines, and 5 axis machining centers. For Premier's current inventory, the AWEA page may show machines such as an LP-3021 bridge mill or a Yama Seiki/AWEA Mega 5 bridge type 5 axis machine.

Is an AWEA LP-3021 a bridge mill?

Yes. The AWEA LP-3021 is part of AWEA's LP bridge type machining center family. Premier's listed 2005 AWEA LP-3021 is described as a CNC bridge mill with Fanuc 18i-MB control, 118 inch X travel, 82 inch Y travel, 30 inch Z travel, CAT 50 taper, 32 station ATC, and 22,000 lb table capacity.

What should I check before buying a used AWEA bridge mill?

Check the control, spindle, travels, table load, distance between columns, tool changer, installed options, service history, power requirements, machine weight, and rigging plan. Large bridge mills can be excellent buys, but only if the machine fits the part, the building, and the budget.

Does Premier sell new AWEA machines?

Premier Equipment sells used CNC machines. Premier does not represent AWEA as a new machine dealer. AWEA logos and names belong to the manufacturer. Premier can help buyers evaluate used AWEA machines that are currently available or discuss similar used CNC options.

What if Premier does not currently have the AWEA model I need?

Contact Premier anyway. Used CNC inventory changes often, and the team may know about incoming equipment or similar machines from other brands. Call (407) 786-2000 or email quotes@premierequipment.com with the model, travel, control, spindle, and application you need.
