Mazak QTEZ10MSY (20”) Multi-Axis CNC Turning Center / QT EZ10MSY /
Specifications (subject to buyer verification):
Maximum Swing………………………………………………… 27.4”
Maximum Machining Length …………………………….. 20.78”
Standard Bar Capacity……………………………………….. 2.5”
Spindle Motor (30min rating) ……………………………. 20 HP
Spindle Speed……………………………………………………. 4200 RPM
Spindle Nose……………………………………………………… A2-6
Number of Tools………………………………………………… 12
Mill Spindle Motor……………………………………………… 7.5 HP
Mill Spindle Speed………………………………………………. 6,000 RPM
Travel (X/Y/Z) …………………………………………………….. 8.5” / 4.00” / 23.75”
Feed Axis Rapid Traverse (X/Y/Z) ……………………….. 1181 / 394 / 1417 IPM
Second Spindle Speed………………………………………… 6,000 RPM
Second Spindle Motor (40% ED) …………………………. 10 HP
Machine Height………., ……………………………………….. 67.9”
Machine Weight……………………………………………….. 12,125 LBS
Equipped With (subject to buyer verification):
Mazatrol SmoothEZ Control
118 PSI high-pressure coolant system with 16 GPM flow
Automatic parts catcher
Extra parts-catcher bucket
LNS Quick Load Servo 80+ bar feeder
Factory-supplied side-discharge hinged chip conveyor
Automatic tool eye for tool setting
Additional LED work light
Mist-collector Royal FX 300 with After Filter Option
Expanded 8 MB program memory
Lots of Live and Static Tooling
Automatic power-on/off function
Operation-complete buzzer
Three-color signal tower
Heavy Duty Royal Rotorack with Deluxe Control
QG-52 Collet part ejector
Royal QG-65 Accu-Length quick-change collet chuck
Royal QG-52 Accu-Length quick-change collet chuck
Standard 10 Inch Kitagawa 3 Jaw Chuck
Standard 6 Inch Kitagawa 3 Jaw Chuck
