Okuma Multus U3000 2SW/1500 (Big Bore) Multi-Axis CNC Turning Center
Specifications (subject to buyer verification):
Swing over Bed: 25.59″
Distance Between Centers 74.33″
Max Recommended Turning Diameter, Upper Turret 25.59″
Max Recommended Turning Diameter, Lower Turret 12.59″
Max Recommended Turning Length with Std Chuck(s): 63.14″
Big Bore configuration
Spindle Speed 50-4200 RPM range
Spindle Motor 30 / 25 / 20 HP, 315 / 245 / 206 ft-lbs torque, 10 min / 20 min / continuous
Spindle bore 3.58”
Bar Capacity 3”
ATC 80 Station
Equipped With (subject to buyer verification):
Okuma OSP P300S-A THiNC Control
AUTO DOOR (LEFT AND RIGHT) WITH RUBBER SWITCH
PARTS CATCHER, 2-SADDLE (2S), SUB SIDE
BB SPINDLE (A2-8) W/SR1781 CYL.+DTUBE F/BB210 CHUCK, LEFT
ATC 80 CAPTO-C6 WITH BAR FEED COVER
Sub Spindle
