DOOSAN VM1260 CNC Mill
SPECIFICATIONS:
DATE OF MANUFACTURE 2013
TABLE SIZE 110.2″ x 49.6″
MAX. TABLE LOAD (EVENLY DISTRIB.) 8,000 LBS
SPINDLE NOSE TO TABLE TOP 7.9″ – 43.3″
X AXIS TRAVEL 98.4″
Y AXIS TRAVEL 49.6″
Z AXIS TRAVEL 35.4″
RAPID TRAVERSE RATE X & Y / Z AXES 472 / 472 IPM
CUTTING FEED RATE ALL AXES 236 IPM
SPINDLE SPEEDS (2 SPEED RANGES) 60 – 6,000 RPM
SPINDLE TAPER CAT 50
SPINDLE MOTOR (PEAK RATING) 30 HP
TOOL CHANGER CAPACITY (SIDE ATC) 40 STATIONS
MAX. TOOL WEIGHT 33.1 LBS
APPROX. DIMENSIONS TBD
APPROX. WEIGHT 68,343 LBS
EQUIPPED WITH:
FANUC 31iB CNC CONTROL WITH 10.4″ LCD SCREEN
RS-232C PORT INTERFACE FOR DNC OPERATION
RIGID TAPPING (SYNCHRONOUS/SOLID TAPPING)
TSUDAKOMA RBA-320L BIG BORE ROTARY TABLE
ROTARY SUPPORT SPINDLE W/FIXTURE PLATE
SPINDLE CHILLER (SPINDLE OIL COOLING SYSTEM)
REMOTE JOG HANDLE (REMOTE PULSE GENERATOR)
STANDARD COOLANT SYSTEM WITH TANK AND PUMP
FULLY ENCLOSED GUARDS, ALL AVAILABLE MANUALS
*****NO TOOLING OR VISES INCLUDED*****
